Description
Specifications:
- Flow rates: up to 200.000 m³/h
- Pressure: up to 7500 Pa
- Belt drive, direct – drive, or coupling drive
- Max temperature values: -20 °C — +300 °C
- Open & straight blade impeller
- Specifically designed for material convey processes with straight and open blade impeller structure
- Good performance in conveying of material through the ventilator and causing no problem in the working conditions with air containing adhesive
- Sheet stell casing
- IE2 high efficiency motors, 3 -phase, 400 V, 50 Hz
On request:
- IE3 premium efficiency motors
- 60 Hz models
- Special design fan up to 900 °C for air transmission
- Hardox, stainless steel or galvanized coating casing
Fields of Applications:
- Granular material conveying in factories
- At dust collection and filtration systems
Industries used in:
- Wood, MDF and Particle Board Industry,
- Paint & Coating Industry,
- Textile Industry,
- Cement Industry,
- Petrochemical Industry,
- Plastic Industry,
