Description

Specifications:

• Flow rates: up to 50.000 m³/h
• Pressure: up to 18.000 Pa
• Belt drive, direct – drive, or coupling drive
• Max temperature values: -20 °C — +300 °C
• Backward curved or straight blade impeller
• Reinforced construction design in compliance with high pressure
• Sheet stell casing
• IE2 high efficiency motors, 3 -phase, 400 V, 50 Hz

On request:

• IE3 premium efficiency motors
• 60 Hz models
• Special design fan up to 900 °C for air transmission
• Stainless steel or galvanized coating casing

Fields of Applications:

• Supplying combustion air for boilers
• At melting furnaces requiring high pressure
• At ventilation operations of mine galleries
• At material convey processes with the help of high pressure air
• At burners requiring high pressure
• At glass washing / drying machine

Industries used in:

• Glass Manufacturing Industry
• Mining Industry
• Casting Industry
• Boiler Manufacturing Industry
• Steel Industry
